OD Value

Thương hiệu Sick

(0 đánh giá)

Giá bán: Vui lòng liên hệ

(Gọi điện, chat Zalo nhận báo giá rẻ hơn)

Simply accurate measurement

The OD Value allows for an easy, precise and economical solution of measuringtasks. It detects even small deviations in dimension, shape, position or excentricity directly in the machine, contactless, precise and during running operation. OD Value convinces with its main features: reliable, user-friendly, effective, universal and efficient. The ideal solution for everyone, who needs to check and verify quality regulary and directly in the process.

Tình trạng:

Còn hàng

Tag: Laser distance sensors ,

Chia sẻ

OD Value AT A GLANCE

Less installation space required than for larger standard sensors with comparable sensing ranges

Reduced risk of mechanical damage due to larger mounting distance from the target object

Avoidance of incorrect switching and more stable processes thanks to high operating reserves

Low mutual interference, several sensors can be installed close to each other

Higher degree of standardization by using the same sensors for different applications

Quick and easy commissioning thanks to visual adjustment indicator and no need for prior parameterization

Long sensor service life thanks to rugged and durable design

Several measurement ranges from 26 mm ... 34 mm to 100 mm ... 500 mm

CMOS receiving element for measurement independent of surface

Easy, LED-based user and teach-in concept

Wide range of models and a wide range of standard interfaces

Laser technology for precise measurement of very small objects

Compact stand-alone device

Excellent price-performance ratio

Advantages

Precision meets quality

With expert-developed intelligent measurement technology which proves its worth in industrial applications time and time again, SICK offers the solution to any challenge which demands maximum measurement accuracy and quality. A pioneering spirit founded on our years of experience and our own innovations in optical sensor technology. We ensure efficient processes while fulfilling the demands of even complex measuring tasks – regardless of surface, diameter, thickness, or width, and regardless of whether an object is to be positioned or measured. This is how we ensure that your products are every bit as perfect as you want them to be. Moreover, SICK’s measurement technology supports quality assurance processes and delivers cost-saving benefits

A point of light is projected onto the measuring object. The light reflected is captured by a light-sensitive receiver at a specific angle. Based on the angle between the send and receive direction, the position of the object is then triangulated (from the Latin “triangulum” = triangle).

4-fold sensing ranges: up to 300% greater detection distance compared to standard sensors.

Detection from a safe distance reduces the risk of collisions and mechanical damage.

Less installation space required: To achieve comparable sensing ranges, IMX sensors can be selected one size smaller than standard sensors.

High flexibility at short distances

Even where measuring distances are short, SICK’s displacement measurement sensors are immensely versatile. They meet the very highest requirements placed on quality and precision in a wide range of measuring tasks and applications.

Checking components

The OD Value distance sensor is lightweight and can therefore be mounted directly on the placement head. It measures the height of the components and application of solder paste in advance and delivers the missing Z data to the 2D vision system of the placement head.

Positioning dispensing needles with precision

For dispensing processes with high repeatability, the absolute distance between dispensing needle and object is very important. The OD Value displacement measurement sensor measures the distance to the object down to the last micrometer and is very cost effective. Thanks to the light spot with a small diameter, it is perfectly suited for measuring the smallest structures.

Measurement of the wane

Two highly precise OD Value displacement measurement sensors mounted opposite each other calculate the exact profile of a board and detect the position of the wane. The vision integrator uses the data during scanning and interpolates the differential between the profiles for optimizing the board, which is then trimmed in the saw.

Precise positioning

Approach the right position every time with a high level of accuracy. With displacement measurement sensors from SICK, grippers and other tools can be positioned exactly without any contact, and with maximum repeatability. Typical applications are "Robot guidance for windshield installation" or "High-accuracy positioning of carriages". Typical industries for the OD Value are robotics, handling and assembly and automotive and parts suppliers.
